• Broad Process Window
• Fast Wetting for SN100C® and SAC alloys - Halide-Free
• Low Post Process Residues
• Lead-Free and Tin-Lead Compatible

Application:

■ NC264-5 is formulated for application via spray, foam, brush, mist, or dip. For spraying, NC264-5 is ready to use directly from its container, no thinning required. When spray fluxing, it is imperative that proper flux coverage and uniformity be achieved and maintained. A dry flux coating of 500-1500 micrograms per square inch is recommended as a starting point.
■ When nitrogen sealed wave solder equipment is used, it is generally necessary to apply slightly more flux than normal as a result of excess drying due to the extended length of the equipment.
■ When foaming, air stones should be supplied with compressed air, free of oil and moisture. Adjust foam head to achieve uniform bubble size for optimum coverage. During foaming applications, it is periodically necessary to add AIM’s Common Flux Thinner to replace that which is lost due through evaporation.
