Siglent SHA860-EMI EMI Measurement Option
Siglent's SHA860-EMI unlocks the EMI measurement kit for SHA860A series of spectrum analyzers (SHA861A/SHA862A) and adds powerful EMI diagnostic capabilities. This option enables EMI pre-compliance testing in accordance with international standards, making it ideal for product development, troubleshooting, and regulatory preparation.
Key Features:
Standards-Based Testing: Supports CISPR 16-1-1 compliant EMI filters (200 Hz, 9 kHz, 120 kHz, 1 MHz) and detectors (Peak, Quasi-Peak, Average).
Automated Scans & Signal Lists: Includes scan, search, and measure sequences for fast and repeatable workflows.
Flexible Limit Line Management: Test against EN550xx, FCC Part 15, GB9254, or user-defined limits with up to three simultaneous traces.
Signal List Reporting: Automatically generates a list of found emissions for fast evaluation and documentation.
Dwell Time & Step Control: Customize scan depth and speed for accurate detection across frequency bands.
Application Areas:
Product development and EMC troubleshooting
Pre-compliance testing before full certification
EMI investigations in the lab or field
Portable EMI diagnostics for remote installations
