• Compliant with DisplayPort 1.2
• Splits or expands a DisplayPort audio/video signal on two DisplayPort monitors
• Display the same image on each monitor, extend the desktop across them, or display in video wall mode where monitors are combined to display as one
• Supports Ultra High Definition (UHD) video resolutions up to 4K @ 60Hz (3840 x 2160) - see System Requirements
• Supports up to 48-bit Deep Color (16 bits per channel)
• Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases

Ideal for digital signage at schools, airports and other public venues that require a DisplayPort video signal to appear on two separate DisplayPort monitors or expanded across both monitors as a video wall.
Splitting, Extending, Multi-Display
■ Splits a DisplayPort video signal to simultaneously display the same signal on two DisplayPort monitors, or expands it across both monitors as in video wall mode
■ Displays can be placed up to 25 ft. away from the splitter/expander; the video source can be up to 16 ft. away from the splitter/expander (6 ft. is recommended).
■ Supports both 4K @ 60Hz (3840 x 2160) UHD video and standard 1080p @ 60Hz (1920x1080) high-definition video Video Standards and Protocols
■ Supports up to 48-bit Deep Color (16 bits per channel) and video resolutions up to 4K Ultra High Definition (UHD), 4K @ 60Hz (3840 x 2160)
■ Complies with HDCP, EDID and DDC
■ Compatible with DisplayPort 1.2
■ Compatible with Apple® Thunderbolt connectors (using P583-Series Mini Displayport to Displayport adapter cable) Installation
■ Plug-and-play; no software or drivers required
■ Easy to install; connect the DisplayPort video source to the hub’s input port, connect the external power supply, and finally connect the two monitors to the output ports Mounting Options
■ Wall-, rack- or pole-mounting; all mounting hardware is included TAA-Compliant for GSA Schedule Purchases
■ Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
