ASG Free Power Supply

FREE ASG POWER SUPPLY with purchase of a TL, A, CL, BLG, or SS Series Driver!

Purchase any of the following drivers before December 31, 2022 and RECEIVE A FREE CORRESPONDING POWER SOURCE!

CLT-60 Single Power Source
Fused input voltage with circuit breaker protected output. Switchable output voltage gives two-speed option on drivers.

TL-Series Precision Torque DC Drivers

  • Automatically stops when pre-set torque is reached
  • Balanced ergonomic design
  • Exceptionally lightweight - 11.5 oz.
  • Reduced vibration and noise
  • Low voltage DC operator
  • Double insulated
TT No. Model Torque Drive Size RPM on High RPM on Low Free Power Supply
10154810 TL-6500 1.5-17 lbf/in 1/4" Hex 700 500 CLT-60
10154811 TL-6500ESD 1.5-17 lbf/in 1/4" Hex 700 500 CLT-60
106SC5601 TL-3000 .25-4.0 ibf/in 1/4" Hex 1000 700 CLT-60
106SC5602 TL-3000 .25-4.0 ibf/in 4.0 mm 1000 700 CLT-60
106SC5603 TL-3000ESD .25-4.0 ibf/in 1/4" Hex 1000 700 CLT-60

BL-Series Brushless Drivers

  • Brushless motor with magnetic switches extends driver life
  • For high production environments
  • Compact design, lightweight
  • No mechanical switches to wear out
  • Precise torque control: driver automatically stops when pre-set torque is reached to eliminate over- or -under- tightening
  • All metal gears
TT No. Model Torque Approx. RPM Drive Size Free Power Supply
106SC4271 BL-5000 2 - 11 lbf/in 1000 4.0 mm T-70 BL Series
10154808 BL-5000 2 - 11 lbf/in 1000 1/4" Hex T-70 BL Series
106SC5501 BL-5000-ESD 2 - 11 lbf/in 1000 1/4" Hex T-70 BL Series
10154809 BL-7000 6.1 - 24 lbf/in 1050 1/4" Hex T-70 BL Series
106SC5506 BL-7000HT 6.1 - 30 lbf/in 740 1/4" Hex T-70 BL Series

BLG-Series Drivers

  • Designed for medium to light torque applications
  • Carbon dust is eliminated; great for cleanroom assembly requirements
  • Anti-static plastic body is ideal for delicate assembly situations
  • Excellent flexibility for small fasteners or vacuum pick-up applications
TT No. Model Torque Approx. RPM Drive Size Free Power Supply
106IE5561 BLG-4000 .4 - 4.8 lbf/in 1000 4.0 mm T-70 BL Series
106IE5560 BLG-4000X .4 - 4.8 lbf/in 1000 1/4" Hex T-70 BL Series

A-Series Torque Drivers

  • For standard to medium torque applications using #1 to #10 screws (2.0 mm to 5.0 mm)
  • Feature a rare-earth magnet motor for more power.
  • Provide considerably higher RPM ranges and torque ranges than corresponding CL-Series tools.
TT No. Model Torque Approx. RPM @30VDC Approx. RPM @20VDC Drive Size Free Power Supply
106SC4113 A-4500 3.5 - 7 lbf/in 1400 1200 1/4" Hex CLT-60
106SC224 A-6500 4.5 - 16 lbf/in 1400 -- 1/4" Hex CLT-60

CL-Series High Performance Drivers*

  • Designed for production environments where torque repeatability is a must to maintain quality standards
  • Recommended wherever cleanroom assembly or static control is an issue
  • Intended for vertical insertion of fasteners
  • Torques are adjusted externally; tamper-proof torques are available
  • Drivers available in Small, Medium, Standard & Large Sizes
TT No. Model Torque Approx. RPM @30VDC Approx. RPM @20VDC Drive Size Free Power Supply
106SC107 CL-2000 2.7 - 27 ozf/in 680 490 4.0 mm CLT-60
106SC4109 CL-3000 3 - 25 ozf/in 1000 670 4.0 mm CLT-60
106SC111 CL-4000 .5 - 4.5 lbf/in 1000 670 4.0 mm CLT-60
10154806 CL-4000 .5 - 4.5 lbf/in 1000 670 1/4" Hex CLT-60
10154807 CL-6500 1.2 - 14 lbf/in 910 600 1/4" Hex CLT-60
106SC120 CL-6500-PS 1.2 - 14 ibf/in 910 600 1/4" Hex CLT-60
10154805 CL-7000 2.6 - 24 ibf/in 750 500 1/4" Hex CLT-60
106SC125 CL-7000-PS 2.6 - 24 ibf/in 750 500 1/4" Hex CLT-60

SS-Series Shock Absorbing/Soft Stop Tools

  • Same as CL tools but with extra shock absorbing features
  • Ideal for use on impact-sensitive equipment
  • Reduces impacts by approximately 80% when fastening
TT No. Model Torque Approx. RPM Drive Size Free Power Supply
106SC285 SS-3000 .26 - 1.74 lbf/in 1000 4.0 mm CLT-60
106SC287 SS-4000 .9 - 4.0 lbf/in 1000 1/4" Hex CLT-60
106SC134 SS-6500 2.2 - 11 lbf/in 900 1/4" Hex CLT-60
106SC136 SS-7000 2.6 - 17.5 lbf/in 750 1/4" Hex CLT-60
