Amphenol RF 000-27025 RF MHV Connector, Straight, Jack, Bulkhead, Round Post, Non-Constant

Our Part #53114.1

Condition:New

Mfr Part #000-27025

Amphenol RF 000-27025
Amphenol RF
Amphenol RF

Amphenol RF 000-27025 RF MHV Connector, Straight, Jack, Bulkhead, Round Post, Non-Constant

Our Part #53114.1

Condition:New

Mfr Part #000-27025

CA Prop 65
RoHS
$60.31EACH
Qty:Price:Savings
1$60.31
100$57.29Save
200$55.49Save
500$54.28Save
1,000$47.04Save
Multiples of: 25
Calif. Prop 65
RoHS

MHV (Miniature High Voltage) Connectors

Features and Benefits:

  • Used for high voltage applications up to 5000 volts DC
  • Quick connect functionality
  • Conforms to MIL 348 standards
  • Nickel plating

MHV connectors are bayonet locking interconnects used for high voltage applications up to 5000 volts.

They are similar in size to, but not designed to mate with the BNC interface. MHV connectors conform to MIL-STD-348 and offer a quick-connect functionality that is used where transmission of high voltage is required.

Applications:

  • Transmission Lines
  • High-Voltage Power Supplies
  • Nuclear Control Instrumentation
  • X-Ray

BrandAmphenol RF
GenderJack
Mounting StyleBulkhead Rear Mount
Termination TypeRound Post
ImpedanceNon-Constant
Contact FinishSilver
Contact MaterialBrass
FinishNickel
Insulation MaterialPTFE
MaterialBrass
Number of Ports1
OrientationStraight
TypeMHV Connectors
$60.31EACH
Qty:Price:Savings
1$60.31
100$57.29Save
200$55.49Save
500$54.28Save
1,000$47.04Save
Multiples of: 25
