Pomona EM6249-48-2# Minigrabber Test Clip To Banana Plug, 48" Long, 5 A, Red, Bulk, 6249 Series
Our Part #37985.1
Condition:New
Mfr Part #EM6249-48-2#
Pomona
Pomona EM6249-48-2# Minigrabber Test Clip To Banana Plug, 48" Long, 5 A, Red, Bulk, 6249 Series
Our Part #37985.1
Condition:New
Mfr Part #EM6249-48-2#
$17.99EACH
- Description
- Specifications
- Documents
- Newly designed Minigrabber® Test Clip Patch Cord offers a high 300 Volt and 5 amp rating.
- Grabber width is a slim .36” (9,14 mm) for easier access to test terminals.
- Grabber hook is gold-plated Beryllium Copper to ensure signal integrity and attaches onto the component leads up to .060” (1,5 mm) O.D.
- Grabber patch cord interfaces directly into the most popular multimeters configured with non-sheathed style banana jacks, including Amprobe, Fluke, H-P, Tektronix and Wavetek.
- Plug is molded directly to the cable in an integral one-piece design for a long-lasting connection.
- Multi-leaf banana spring material is nickel-plated Beryllium Copper for extended insertion life & and low contact resistance.
- Banana plug features top and side stacking for added test versatility.
- High strand count silicone insulated wire offers excellent flexibility and high-temperature resistance.
Brand: Pomona
Series: 6249 Series
Cable Length: 48"
Color: Red
Current: 5 A
Finish: Nickel Plated
Insulation Material: Polypropylene
Material: Beryllium Copper/Brass
Voltage Rating: 300 V
Wire Size: 18 AWG
