Pomona 5014/POM Standard DIP Clip, 14 Pins w/Nickel Silver Contacts, Blue

Our Part #35236.1

Condition:New

Mfr Part #5014/POM

Pomona 5014/POM
Pomona
Pomona

Pomona 5014/POM Standard DIP Clip, 14 Pins w/Nickel Silver Contacts, Blue

Our Part #35236.1

Condition:New

Mfr Part #5014/POM

$17.99EACH
Estimated Mfr lead time:17 Days
  • Contacts (.040" wide on lower end) are serrated for the best electrical contact.
  • .025" X .028" serrated test points on upper end will accept wire wraps or mini test clips.
  • Molded barriers between contacts allows live board connections without accidental shorting of contacts.
  • Can also be used as an insertion tool for DIPs.
  • Contacts are spring tempered Nickel Silver or Gold Plated Beryllium Copper alloy. Oxide penetrating clips have a roughened stainless steel surface treatment.
  • Open back option allows probing on the chip leads while clip is attached.

The Pomona 5014/POM is a 14 Pin With Nickel Silver Contacts Dip Clip. Pomona DIP Clip® test clips are designed for testing dual-in-line IC packages on PC boards. These devices incorporate many built-in features that assure a positive electrical connection as well as hands-free testing. Pomona's DIP Clip® test clips are perfect for emulation, field service, failure analysis, and for use with logic analyzers.

BrandPomona
ColorBlue
Contact FinishNickel Silver
Contact MaterialBeryllium Copper
$17.99EACH
Estimated Mfr lead time:17 Days
