• Intelligent Crimping System Technology includes a pressure sensor that monitors the crimping force of each crimp and provides the operator a visual and audible alert if the force is belows specifications
• State of the art 18V lithium ion (Li-ion) battery provides 70% more cycles per charge and faster cycle times
• LED light provides the operator with the battery charge and tool maintenance status
• In-Line tool style is light weight and very easy to control
• One trigger controls all tool functions
• Crimping head rotates 350°
• Tools automatically retract when the crimping cycle is complete
• Overmolded tacky grip areas make gripping the tool easier and more comfortable
• LED work light illuminates dark work areas
• Greenlee battery-powered crimping tools now use bio-degradable oil
• Smart chargers control the charging current, charging voltage and battery temperature to maximize battery life
• Accepts Greenlee KC22 and KA22 series crimping dies
• Includes 04292 die adapters which can be used with all industry "W" style crimping dies and Greenlee KD6 style dies
• Available with 120V, 12V or 230V battery charger or with 120V or 230V corded adapter in place of batteries and charger

Equipped with Bluetooth™ Communication enabled via the Greenlee Gator Eye app. Features LED display screen communicating pressure and battery levels as well as tool diagnostics with real-time tool feedback.

Product Details:

• Sub Brand : Gator
• Type : Die style crimper
• Application : 6 Ton Crimping
• Standard : C/US UL Listed
• Wire Size : 8 AWG - 600 kcmil Cu
• Wire Size : 8 AWG - 350 kcmil Al
• Overall Length : 15.75 IN (438mm)
• Crimping Force : 12,000 lbs. (53 kN)
• Crimping Capacity : 600 kcmil (MCM) Copper
• Crimping Capacity : 350 kcmil (MCM) Al
• Connector Type : Color-coded lugs and splices
• Handle Type : In-Line Style with over molded rubber grip
