Altech
Altech 40.310 Terminal Strip, Panel Mount, ATSF2.5/2, 10 Pole, 10mm, 600 V, 30 A, M3, ATS Series
Our Part #10120213
Condition:New
Mfr Part #40.310
Altech
Altech 40.310 Terminal Strip, Panel Mount, ATSF2.5/2, 10 Pole, 10mm, 600 V, 30 A, M3, ATS Series
Our Part #10120213
Condition:New
Mfr Part #40.310
$4.68EACH
Multiples of: 50
- Description
- Specifications
- Documents
- Quick and Efficient Wire-to-Wire connection solution
- Modern Replacement for traditional Double-Row Barrier Style Terminal Blocks
- Touch-proof design to eliminate shorts
- Easy to cut to length by using hacksaw or utility knife
- Safe, Gas-tight connection
- Reliable connection utilizing a precision machined tubular screw clamp insert
- Accessories for convenient wire installation and usage
Brand: Altech
Wire Size: 22 AWG
Number of Poles: 10
Series: ATS Series
Certifications: CE, UL, IEC
Color: White
Current Rating: VDE: 26A, UL: 30A
Length: 97 mm
Material: Zinc Yellow Chromated Steel
Maximum Torque: 5.3 lb./in.
Maximum Wire Size: 10<choice id="794"> AWG
Package Quantity: 50/Pk
Pin Spacing: 10mm
Screw Size: M3
Strip Length: 6.0 mm
Terminal Diameter: 3.5 mm
Torque: 0.6 Nm
Voltage Rating: 600 V
$4.68EACH
Multiples of: 50
