Altech
Altech 40.011 Terminal Strip, Panel Mount, ATS1.5/2, 11 Pole, 8mm, 300 V, 20 A, M2.5, ATS Series
Our Part #10120194
Condition:New
Mfr Part #40.011
Altech
Altech 40.011 Terminal Strip, Panel Mount, ATS1.5/2, 11 Pole, 8mm, 300 V, 20 A, M2.5, ATS Series
Our Part #10120194
Condition:New
Mfr Part #40.011
$EACH
Multiples of: 50
- Description
- Specifications
- Documents
- Quick and Efficient Wire-to-Wire connection solution
- Modern Replacement for traditional Double-Row Barrier Style Terminal Blocks
- Touch-proof design to eliminate shorts
- Easy to cut to length by using hacksaw or utility knife
- Safe, Gas-tight connection
- Reliable connection utilizing a precision machined tubular screw clamp insert
- Accessories for convenient wire installation and usage
Brand: Altech
Wire Size AWG: 22 AWG
Number of Poles: 11
Series: ATS Series
Certifications: CE, UL, IEC
Color: White
Current Rating: VDE: 15A, UL: 20A
Length: 85.1 mm
Material: Zinc Yellow Chromated Steel
Maximum Torque: 4.4 lb./in.
Maximum Wire Size: 12<choice id="794"> AWG
Package Quantity: 50/Pk
Pin Spacing: 8mm
Screw Size: M2.5
Strip Length: 5.0 mm
Terminal Diameter: 2.8 mm
Torque: 0.5 Nm
Voltage Rating: 400 V
$EACH
Multiples of: 50
