Excelta LazerLine High-Precision Specialty Cutters
In the 1950s, Excelta introduced specialized watchmaking hand tools to the aerospace industry. Today, Excelta is the preferred choice for critical applications that combine extreme precision with the highest levels of human craftsmanship.
Excelta’s LazerLine cutters are made from premium, laser-cut steel with advanced CNC machining to deliver ultra-precise cutting action for the most critical applications.
- CNC-machined from premium AISI 52/100 carbon tool steel
- Cutting edges induction hardened to RHC 63-65
- ESD-safe grips featuring TealShield™ antimicrobial additives
Angulated Head Cutters
Some workpieces are so tight that you can’t move your tools into position without blocking your own view. Tired of making blind cuts? The angulated head reorients the cutter—and your hand—away from your line of sight.
| Part Number | Description | Type of Head | Size |
| 7104E | Maximum Flush Cut, 6" Carbon Steel, 28 AWG | 50° Angulated Head | Large |
| 7172E | Maximum Flush Cut, 6" Carbon Steel, 20 AWG | 50° Angulated Head | Large |
| 7175E | Maximum Flush Cut, 6" Carbon Steel, 26 AWG | 50° Angulated Head | Miniature |
| 7182E | Maximum Flush Cut, 6" Carbon Steel, 22 AWG | 50° Angulated Head | Medium |
| 7204E | Maximum Flush Cut, 6" Carbon Steel, 22 AWG | 50° Angulated Head | Large |
| 7272E | Maximum Flush Cut, 6" Carbon Steel, 22 AWG | 50° Angulated Head | Large |
| 7275E | Maximum Flush Cut, 6" Carbon Steel, 28 AWG | 50° Angulated Head | Miniature |
| 7282E | Maximum Flush Cut, 6" Carbon Steel, 26 AWG | 50° Angulated Head | Medium |
| 7375E | Maximum Flush Cut, 6" Carbon Steel, 30 AWG | 50° Angulated Head | Miniature |
| 7376E | Maximum Flush Cut, 6" Carbon Steel, 30 AWG | 40° Angulated Head | Miniature |
Relieved Head Cutters
Working on crowded SMD boards? Need to cut larger leads? The long nose and fine tip of a relieved head cutter gives you the reach, the leverage, and the precision you need in confined spaces.
| Part Number | Description | Type of Head | Size |
| 7149E | Cutters - Long Nose Fine .03" x .022" Tip | Relieved Head | Small |
| 7170E | Cutters - Long Nose Fine .02" x .02" Tip | Relieved Head | Medium |
| 7170EA | Cutters - Long Nose Fine .03" x .02" Tip | Relieved Head | Medium |
| 7171E | Cutters - Long Nose Fine .02" x .015" Tip | Relieved Head | Miniature |
| 7270E | Cutters - Long Nose Fine .02" x .02" Tip, Short Handle | Relieved Head | Medium |
| 7270EA | Cutters - Long Nose Fine .03" x .02" Tip, Short Handle | Relieved Head | Medium |
| 7271E | Cutters - Long Nose Fine .02" x .015" Tip, Short Handle | Relieved Head | Miniature |
| 7371E | Cutters - Long Nose Fine .125" Tip | Relieved Head | Miniature |
Transverse End Cutters
Have you ever tried to rotate your cutting angle 90°, only to realize that the workpiece is so tight that you can’t maneuver the cutting head into position? These transverse end cutters are the solution.
| Part Number | Description | Type of Head |
| 7173E | Cutters, Optimum Flush Cut, 6" Carbon Steel, 24 AWG | Transverse End |
| 7174E | Cutters, Optimum Flush Cut, 6" Carbon Steel, 24 AWG | Transverse End |
| 7273E | Cutters, Optimum Flush Cut, 4.25" Carbon Steel, 24 AWG | Mini Transverse End |
| 7274E | Cutters, Optimum Flush Cut, 4.25" Carbon Steel, 24 AWG | Mini Transverse End |
